How to Disable Software Z-Stop in Marlin Firmware
Marlin firmware offers a powerful feature called Software Z-Stop, allowing for precise Z-height adjustments without relying solely on hardware limit switches. However, some users find it unnecessary or prefer the simpler approach of using hardware limit switches. This guide explains how to disable Software Z-Stop in your Marlin configuration, along with troubleshooting common issues.
Understanding Software Z-Stop and Its Implications
Before disabling it, understanding Software Z-Stop is crucial. This feature uses the endstop as a reference point, but then relies on the Z-probe or other sensor to determine the actual height of the bed. This allows for more accurate bed leveling, especially on uneven surfaces. Disabling it means your printer will solely depend on the hardware Z-stop switch for determining the Z-zero position.
Disabling Software Z-Stop: Steps and Considerations
The process of disabling Software Z-Stop involves modifying your Marlin configuration file (Configuration.h). Specifically, you need to change the Z_SAFE_HOMING definition. Here's how:
-
Locate your
Configuration.hfile: This is found within your Marlin firmware directory. -
Find the
#define Z_SAFE_HOMINGline: Search for this line within the file. -
Comment out the line: Add
//at the beginning of the line to comment it out. This effectively disables the feature. Your line should look like this:// #define Z_SAFE_HOMING -
Compile and Upload: Compile your modified Marlin firmware and upload it to your 3D printer's microcontroller. Remember to always back up your original
Configuration.hfile before making any changes.
Important Considerations:
-
Hardware Z-Stop Calibration: After disabling Software Z-Stop, ensure your hardware Z-stop switch is correctly calibrated and positioned. An incorrectly calibrated switch can lead to crashes and damage.
-
Z-Probe Calibration (if applicable): If you were using a Z-probe with Software Z-Stop, you might need to adjust your Z-probe offset after disabling the feature.
-
Potential Issues: Disabling Software Z-Stop might result in less precise bed leveling, especially on uneven surfaces. You may need to manually adjust your bed leveling more frequently.
Troubleshooting Common Issues After Disabling Software Z-Stop
-
Printer crashes into the bed: This indicates a problem with your hardware Z-stop switch placement or calibration. Check the switch position and recalibrate if needed.
-
Inconsistent print height: This points towards an issue with your bed leveling. Manually level your bed using the knobs on your printer.
-
Unexpected behavior: If you encounter any unexpected behaviors, double-check your
Configuration.hfile to ensure other settings haven't inadvertently been affected. Revert to your backed-up version if necessary.
Alternative Methods (Depending on Your Setup)
While the above method focuses on disabling the Software Z-Stop feature itself, alternative approaches might be necessary depending on your specific printer setup and Marlin configuration:
-
Adjusting
Z_MIN_POS: This value defines the minimum Z position. Modifying this might seem like a solution, but it's crucial to note this is not the same as disabling Software Z-Stop. It merely alters the minimum Z position used by the firmware. -
Reviewing related macros: Some Marlin configurations use macros to handle homing and endstop functionality. Review those macros for any code directly related to Software Z-Stop.
Conclusion
Disabling Software Z-Stop in Marlin is a straightforward process, but it's essential to understand the implications. Proper calibration of your hardware Z-stop switch and potential adjustments to your bed leveling are crucial to avoid damage and ensure successful prints. Always back up your configuration files and proceed with caution. Remember to consult your specific printer's documentation and the Marlin documentation for detailed information specific to your setup.
